(Solved) : Determine Pressure C B Determine Pressure B C Determine X Component Force Divider Due Flu Q40862363 . . .

M Review Water enters the divider fixture through pipe A (diameter, DA= 65 mm) with a velocity magnitude 5 m/s and a pressureA. Determine the pressure at C.

B. Determine the pressure at B.

C. Determine the  x-component of the force on thedivider due to the fluid. Indicate the direction of this componentwith the sign; a negative sign indicating a direction in thenegative x-direction.

D. Determine the y -component of the force needed to maintainthe fixture in place.   Indicate the direction ofthis component with the sign; a negative sign indicating adirection in the negative y-direction.

M Review Water enters the divider fixture through pipe A (diameter, DA= 65 mm) with a velocity magnitude 5 m/s and a pressure 44 kPa. The divider fixture divides the flow into two streams, one exiting through pipe B (diameter, DB = 32 mm and the other exiting through pipe C (diameter, Dc = 52 mm). Pipe B is at angle of @= 30° with respect to the negative) z-axis. The velocity magnitude at C is Vc = 5.625 m/s. The pipes and fixture may be assumed in the horizontal plane and frictional effects may be neglected. DB DC divider Part A Determine the pressure at C.
